A.O. Smith WHC1502-CNT-00 LB/LW Control Board WHC 1502

Repair

Repair Price: $ 904.00

Repair Now

Purchase

https://controlrepair.com/web/image/product.template/70183/image_1920?unique=e4684b7
  • Condition

Purchase Price: $ 0.00 $ 0.00 904.0 USD

$ 0.00

This combination does not exist.

Add to Cart

CSL Part Number: 86568
Product Overview: The A.O. Smith WHC1502-CNT-00 is a microprocessor-based control board used in commercial gas-fired boilers and water heaters, including the Genesis series and LB/LW models. It manages ignition sequencing, flame sensing, combustion blower control, and safety interlocks by monitoring sensors and operating multiple 24VDC relays. The board features onboard power supplies (5V, 15V, -9V, 24V), a diagnostic LED display, and multiple connectors for thermistors, pressure switches, flame sensors, and actuators. Common configurations include model numbers 400C0129 and revision variants, manufactured by A.O. Smith (also known as TDI).
Category: Control Board
Manufacturer: A.O. Smith
Alternate Manufacturer Names: TDI
Manufacturer Part Number: WHC1502-CNT-00
Also Known As(AKA): 400C0129 Rev M 210128
Other Synonyms: TDI

Common Failures

A.O. Smith control boards for boilers may exhibit issues such as defective transistors, faulty solder joints, resistor failure, and relay problems. These component-level concerns can contribute to symptoms including sensor-related faults, control errors, ignition control issues, and power supply concerns. Heat-related damage to components is sometimes observed during evaluation.

Repair Approach

Repairs typically involve component-level replacement of transistors, relays, resistors, and capacitors as needed. Preventative replacement of electrolytic capacitors and relays may be performed to address common wear points. Solder joint reflow and connector replacement are performed when required. Specialized test fixtures support the evaluation and repair process.

Testing & Quality

Each board is tested following repair to verify proper operation. Testing may include diagnostic procedures, voltage verification, signal integrity checks, and functional testing of board operations. Boards are monitored during testing to confirm stable performance before being returned.

Service and repair your broken A.O. Smith part


We can repair your A.O. Smith model WHC1502-CNT-00 in our facility. Let our skilled technicians get your A.O. Smith back in operation quickly.
