Repair
Repair Price: $ 1,594.00
Purchase
CSL Part Number: 12282
Product Overview: The Excel XL750 Robot Control Module is a programmable controller for industrial robotic systems, commonly used in automated manufacturing equipment such as injection molding machines. It features a keypad interface, LCD display, non-volatile SRAM for program storage (DS1225Y or DS1230Y), and integrated safety circuit with E-stop functionality. The module operates on 24V or 120VAC input (configurable via jumpers) and provides relay outputs for controlling robotic motion sequences including mold open/close and ejector positioning.
Category: Robotic
Manufacturer: AEC
Manufacturer Synonyms: Application Engineering Corporation
Manufacturer Part Number: A0805427
Repair price does not include repair of bad keypads.
Common Failures
Units received for repair have exhibited various issues including intermittent faults, indicator light errors, display irregularities, and non-functionality. Evaluation findings have included damaged connector pins, loose or disconnected connections, components requiring replacement, and corrosion affecting electrical contact. Some units exhibited intermittent behavior during testing.
Repair Approach
Repairs typically involve replacing defective components such as switches, integrated circuits, capacitors, and resistors as identified during evaluation. When mechanical issues such as damaged pins or corrosion are found, connections are cleaned and repaired as needed. Missing hardware is reinstalled to restore proper assembly. Component-level repairs are performed based on diagnostic findings to restore functionality.
Testing & Quality
Following repair, units are tested using appropriate diagnostic procedures and functional testing to verify operation. Display and input functions are checked, and connections are secured as needed. Testing procedures include verification of component operation and review of repair work to confirm that quality standards have been met.
Service and repair your broken AEC part
We can repair your AEC model A0805427 in our facility. Let our skilled technicians get your AEC back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
