Align JC-10AN JC-10AN Circuit Board
Repair
Call for price
Purchase
CSL Part Number: 102947
Product Overview: The JC-10AN is a control board manufactured by Align for industrial control applications. It uses SCR-based power control circuitry, featuring 400V 6A SCRs rated for 100A peak current in TO-220AB packages. The board provides output control functions and is typically used in equipment requiring regulated power delivery or motor control operations.
Category: Control Board
Manufacturer: Align
Manufacturer Part Number: JC-10AN
Power supplies are tested with a minimum 4-hour burn-in, under load.
Common Failures
One notable issue with this product involves smoke emanating from the board, which is often caused by the presence of oil under a metal plate leading to electrical shorts. This typically affects components on the board that can result in malfunctioning or damage.
Repair Approach
To address reported problems, we perform a careful inspection and evaluate any loose or damaged connections on the board. Our goal is to ensure all components are securely in place and functioning as intended. We conduct diagnostic testing to identify potential issues before providing a quotation for any necessary repair work.
Testing & Quality
Post-repair, the product undergoes thorough testing. The testing process includes verification of solder joint integrity and operational checks under load. Units are cleared only after passing all diagnostic and operational tests.
Service and repair your broken Align part
We can repair your Align model JC-10AN in our facility. Let our skilled technicians get your Align back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
