Repair Price: $ 394.00
Purchase
CSL Part Number: 87238
Product Overview: The Ameritek B20912CNC is a relay card used for switching and control functions in industrial automation systems. It features multiple relay outputs for actuating devices such as solenoids, valves, and motors in manufacturing equipment and process control applications. The board includes DIP switch configuration, dual op-amp circuitry, and wire input/output connections for interfacing with control systems.
Category: Relay Card
Manufacturer: Ameritek
Manufacturer Part Number: B20912CNC
Common Failures
Common issues with this product include defective solder joints and malfunctioning components such as dual wipe DIP sockets and op-amps.
Repair Approach
The repair process often involves reflowing solder joints to address cracks identified around wire inputs and outputs. Preventative replacements may include capacitors and dip switches. Comprehensive diagnostic testing is conducted to verify components meet tolerance specifications.
Testing & Quality
Diagnostic tests are performed on critical components, including resistors, diodes, transistors, and capacitors. The final quality assurance process includes inspection and sign-off by a qualified technician. All products undergo component-level testing to confirm operational integrity.
Service and repair your broken Ameritek part
We can repair your Ameritek model B20912CNC in our facility. Let our skilled technicians get your Ameritek back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
