Repair
Repair Price: $ 3,268.00
Purchase
CSL Part Number: 33858
Product Overview: The Baldor ZD18H205-E is a 5-horsepower AC flux vector motor control rated for 230V input. It belongs to Baldor's Series 18H line of variable frequency drives designed for precise speed and torque control of three-phase AC motors. Flux vector technology enables high-performance applications requiring dynamic response and accurate motor control at varying speeds. Commonly used in industrial machinery including paper processing equipment, CNC systems, and spindle drive applications where precise motor regulation is critical.
Category: AC Motor Controls
Manufacturer: Baldor Electric
Manufacturer Synonyms: ABB
Manufacturer Part Number: ZD18H205-E
Series: Series 18H AC Flux Vector Control
Also Known As(AKA): 18H
We repair these controls w/ motors and tach feedback.
Common Failures
Frequently reported issues include inability to control spindle motors, missing DC voltage, and units not driving motors properly. Problems such as excessive current draw and units tripping power base faults have also been noted. In some cases, units have undergone previous repair attempts that resulted in additional damage.
Repair Approaches
Common repairs include replacing defective components such as IGBT modules, gate optos, and current transducers. Other repairs involve addressing solder joint issues. Some units cannot be repaired due to excessive damage or the inability to resolve issues within a reasonable timeframe, such as missing phases or persistent power base faults.
Testing & Quality
Units are tested during attempts to drive motors with 3-phase power. Some units have shown discrepancies in expected performance, such as incorrect current readings or behavior consistent with missing phases during motor operation. These tests help determine whether a unit can be returned to serviceable condition.
Service and repair your broken Baldor Electric part
We can repair your Baldor Electric model ZD18H205-E in our facility. Let our skilled technicians get your Baldor Electric back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
