Repair
Repair Price: $ 572.00
Purchase
CSL Part Number: 85958
Product Overview: The Celesco MT2E-30L-14-316-C1 is a cable-actuated position sensor that converts linear displacement into quadrature-encoded electrical signals. It features a 30-foot measurement range with a spring-loaded, retractable stainless steel braided cable. The internal encoder produces TTL quadrature output (A and B channels, 90 degrees out of phase, 50% duty cycle) at 1000 pulses per revolution, allowing precise position and direction tracking. The 316 stainless steel housing provides corrosion resistance for industrial environments. Common applications include material handling systems, cranes, construction equipment, and any machinery requiring linear position feedback over extended distances.
Category: Transducer
Manufacturer: Celesco
Alternate Manufacturer Names: Measurement Specialties
Manufacturer Part Number: MT2E-30L-14-316-C1
Also Known As(AKA): TE Connectivity
Other Synonyms: Measurement Specialties
Common Failures
Common issues observed include defective or broken cables, which may result in interrupted functionality such as failure to encode or retract properly. Other issues include missing hardware or incorrect cable installations that can lead to improper operation or physical damage.
Repair Approach
Repairs typically involve replacing defective cables and components, ensuring correct installation of hardware, and restoring mechanical integrity. Work may also include cleaning, rewiring, and resecuring loose or missing parts. Components such as ring terminals and rubber bumpers are commonly replaced or added during repairs.
Testing & Quality
Post-repair testing includes burn-in testing with load, verifying that outputs operate at a 50% duty cycle and in the correct phase relationship. Units are tested to confirm proper functionality, including quadrature outputs and mechanical operations.
Service and repair your broken Celesco part
We can repair your Celesco model MT2E-30L-14-316-C1 in our facility. Let our skilled technicians get your Celesco back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
