Repair
Repair Price: $ 428.00
Purchase
CSL Part Number: 15364
Product Overview: The System 547 is a 1/3 HP motor control board manufactured by Chemcut Corp. (PCA 47961/4796). It regulates AC motor operation in industrial equipment, commonly found in PCB manufacturing systems and related chemical processing machinery. The board uses DPDT relays with 24VDC and 120VAC coil configurations, SCRs for motor switching, and feedback circuitry including tachometer input for speed control. It is designed for controlling fractional horsepower motors in automated industrial processes.
Category: Motor Controls
Manufacturer: Chemcut Corp.
Manufacturer Part Number: PCA 47961 (4796)
Common Failures
Common issues identified with this product include defective components such as relays, capacitors, and resistors, along with areas that suffered from burn damage. These failures were typically accompanied by physical damage to circuit board traces.
Repair Approach
The repair procedure involved replacing defective relays and sockets, as well as performing circuit board trace repairs to address damaged traces. Additionally, the repair included thorough cleaning and burn damage repair.
Testing & Quality
After repairs, the product underwent testing using a motor with an attached tachometer to assess performance under operational conditions. The product passed testing to confirm the repairs performed.
Service and repair your broken Chemcut Corp. part
We can repair your Chemcut Corp. model PCA 47961 (4796) in our facility. Let our skilled technicians get your Chemcut Corp. back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
