Repair
Repair Price: $ 532.00
Purchase
CSL Part Number: 87851
Product Overview: The Cincinnati Inc. 817549 Rev F (also known as 817546 Rev B) is a control board used in Cincinnati paper handling or forming equipment. It manages operator interface functions including stroke control via a potentiometer, rapid traverse directional controls, and multiple push-button switch inputs for machine operation and safety functions. The board uses standard through-hole components including axial electrolytic capacitors, metal film resistors, and mechanical switches with replaceable contacts. It connects to other system modules via ribbon cable interfaces and operates as part of the larger 817972 technical group system.
Category: Control Board
Manufacturer: Cincinnati Inc.
Manufacturer Part Number: 817549 Rev F
Also Known As(AKA): 817546 Rev B
Common Failures
Several issues have been noted including incorrect component values leading to voltage discrepancies, burnt sections of the circuit board, broken ribbon cable pins, defective solder joints, and worn-out potentiometers. Common symptoms include malfunctioning capacitors, resistors with incorrect values, and damaged switches and connectors.
Repair Approach
Repairs typically involve replacing and upgrading capacitors to correct voltage levels, fixing broken pins on ribbon cables, cleaning burn damage and applying solder masks, and repairing or replacing defective switches and potentiometers. Solder joints are repaired to ensure proper electrical connections.
Testing & Quality
After repairs are completed, comprehensive testing is conducted, including burn-in tests, to verify component function. This includes both operational and load testing to confirm that functionalities meet quality and operational standards.
Repair your broken Cincinnati Inc. part
We can repair your Cincinnati Inc. model 817549 Rev F .
Please note: our repair turnaround time may be longer than our standard lead times for this item.
Step 1 -
Click the green button above, "Repair Now," and add to your RMA.
Step 2 -
Print the RMA form that is emailed to you, and put it in a box with the parts for repair.
Step 3 -
Mail the box to the address on the RMA.
You will be sent an authorization for repair via email. Your approval is needed before any work is started.
Once the user has seen at least one product this snippet will be visible.
