CSL Part Number: 87046
Product Overview: The OBS Hydraulic Press Operator Pendant (Cincinnati part number 821502 with 825718) is a multi-board control panel assembly used on Cincinnati 175-ton hydraulic presses. It integrates operator interface switches, numerical keypad, LCD display, memory modules, relay boards, and power supplies to regulate press operation and positioning control. The system monitors resolver positioning feedback and manages output zones for precise die control during stamping or forming operations. Key internal boards include analog control units, memory modules with battery backup, AC monitoring, and relay control circuitry.
Category: Control Panel
Manufacturer: Cincinnati Inc.
Manufacturer Part Number: 821502 with 825718
Common Failures
Common issues reported with the Cincinnati 175 Ton control panel include difficulty regulating tolerances and the press stopping when knockouts are installed. These problems are often associated with the analog unit's resolver positioning accuracy, as well as potential issues with output boards, memory modules, and switches. Physical damage to control panel components and power supply failures are also frequently observed during evaluation.
Repair Approach
The repair process typically begins with restoring the mechanical integrity of the panel, which may include adding standoffs for board support, repairing or replacing damaged cables, and installing a new keypad. Electronic components are then individually tested and repaired or replaced as needed. Defective parts are identified through visual inspection and electrical testing. When obsolete parts are involved, we seek appropriate replacement solutions from available sources.
Testing & Quality
After repairs are completed, each board undergoes individual functional testing before the entire assembly is tested. This evaluation is intended to verify that all components function properly together. CSL provides a one-year warranty on repaired parts and labor in accordance with our standard warranty policy. Testing is conducted to confirm the control panel meets operational standards before return.
Repair your broken Cincinnati Inc. part
We can repair your Cincinnati Inc. model 821502 with 825718 .
Please note: our repair turnaround time may be longer than our standard lead times for this item.
Step 1 -
Click the green button above, "Repair Now," and add to your RMA.
Step 2 -
Print the RMA form that is emailed to you, and put it in a box with the parts for repair.
Step 3 -
Mail the box to the address on the RMA.
You will be sent an authorization for repair via email. Your approval is needed before any work is started.
