Repair
Repair Price: $ 994.00
Purchase
CSL Part Number: 87716
Product Overview: The Accelnet MACRO DC Drive 90VDC 6A (model AMP-090-18) is a compact servo drive from Copley Controls designed to control DC brush motors in precision motion applications. It accepts 60VDC input and delivers up to 90VDC output at 6 amperes continuous current. Part of the Accelnet series, it features programmable motion profiles and can be configured via software for various motor control tasks. Commonly used in automated machinery, robotics, and positioning systems requiring smooth acceleration and deceleration control.
Category: Servo Controls
Manufacturer: Copley Controls
Manufacturer Part Number: AMP-090-18
Series: Copley Accelnet Series
Also Known As(AKA): 800-1689
Common Failures
Two primary issues were observed during evaluation. The first involved a voltage configuration issue, where settings resulted in a 91V output. Settings were adjusted to restore compatibility. The second issue included a red error light upon power-up, related to stored faults that prevented the unit from enabling.
Repair Approach
The voltage configuration issue was addressed by adjusting program settings to align with motor specifications. For the red error light, diagnostic tests identified and cleared stored faults. Multiple capacitors were replaced as a preventative measure to support stability.
Testing & Quality
Units underwent comprehensive burn-in testing with a motor to confirm operational stability. No faults were detected after adjustments and replacements. The units also passed diagnostic testing prior to being returned.
Service and repair your broken Copley Controls part
We can repair your Copley Controls model AMP-090-18 in our facility. Let our skilled technicians get your Copley Controls back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
