Repair
Repair Price: $ 2,096.00
Purchase
CSL Part Number: 80782
Product Overview: A brushless positioning servo drive operating on 230 VAC (110/220 VAC input) for precise motion and position control of brushless servo motors. It supports both computer and external control with communication capability and runs programs stored via battery backup. Commonly used in industrial automation and paper-handling equipment.
Category: AC Motor Controls
Manufacturer: Emerson
Manufacturer Part Number: FX-208
Series: FX Positioning Drive
Also Known As(AKA): 960135-01
The FX series of brushless positioning servo drives are a reliable industry workhorse. Our technicians will repair your drive, saving you 1000's in retrofit costs.
Common Failures
Several units were returned with a variety of issues, including failure to power up, failure to hold a program, fault errors ("4" and "8"), and communication errors. A common symptom was the unit's failure to start, often accompanied by fault codes indicating issues with the logic supply or output board.
Repair Approach
Repairs involved thorough verification of complaints followed by specific interventions when the problems were identified. Common solutions included replacing faulty capacitors and output boards, cleaning and reinserting connectors, and replacing backup batteries. In some cases, problems could not be reproduced during initial testing, but thorough evaluation and validation were still performed.
Testing & Quality
Units underwent extensive testing after repair, including burn-in under load, verification of operation, and communication testing. Units were powered up and down multiple times to confirm stability. In certain cases, units were run continuously for extended periods or on specific motors to verify operational reliability.
Service and repair your broken Emerson part
We can repair your Emerson model FX-208 in our facility. Let our skilled technicians get your Emerson back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
