Repair
Repair Price: $ 384.00
Purchase
CSL Part Number: 33176
Product Overview: The Gefran TPD3S/M is a 1/16 DIN format timer with LED display and mechanical thumbwheel setpoint adjustment. It provides time delay functions for industrial control applications. This model features a compact panel-mount design suitable for integration into machinery control panels, packaging equipment, and process automation systems. The unit uses standard relay output switching for load control. Note that this is a specialty timer model with limited distribution availability.
Category: Timers
Manufacturer: Gefran
Manufacturer Part Number: TPD3S/M
Series: Timer 1/16 DIN
Common Failures
This product may experience issues related to timekeeping functions and damage to the ULN2004 integrated circuit. These failures can occur even when diagnostic testing does not reveal obvious faults in components or circuit configuration.
Repair Approach
The repair process may include replacement of capacitors and integrated circuits as needed. In some cases, physical damage such as broken case components or front plates may also require attention. Each unit is evaluated individually to determine the appropriate repair scope.
Testing & Quality
Units undergo comprehensive diagnostic testing, including component checks and circuit configuration assessments. Component replacements are performed as required based on evaluation findings. All repaired units are thoroughly tested to verify proper operation before return to the customer.
Service and repair your broken Gefran part
We can repair your Gefran model TPD3S/M in our facility. Let our skilled technicians get your Gefran back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
