CSL Part Number: 109016
Product Overview: The Heater Control Board (GCB05) is a power control module manufactured by Glunz & Jensen A/S for regulating heating elements in industrial processing equipment. It uses triac-based switching to control heater outputs and incorporates relay-driven circuits for temperature management. This board is commonly found in Glunz & Jensen plate processing systems where precise thermal control is critical. The design includes multiple output stages, each controlled by dedicated triacs and optocouplers, with protective components including fuses and MOVs. Alternative part numbers include VIC-2, GI9915, NR0083, and 16423C.
Category: Power Controls
Manufacturer: Glunz & Jensen A/S
Manufacturer Part Number: GCB05
Also Known As(AKA): VIC-2, GI9915, NR0083, 16423C
Please send in wiring diagrams and provide a good problem description
Common Failures
A frequently observed issue with this product is the failure of the heater board, which can result in non-functional heating. The primary cause is typically a defective triac component. In some cases, issues have also arisen from a non-operational relay and poorly soldered connections.
Repair Approach
The repair process often includes replacing the defective triac, checking the optocoupler for damage, inspecting all fuses, and resoldering any poorly done joints. Occasionally, relays require testing and verification, potentially needing replacement if found to be defective.
Testing & Quality
Repairs undergo a thorough diagnostic process, including component checks and limited power-up tests to verify the integrity of repairs. Testing can identify other defective parts contributing to the reported symptoms. However, comprehensive system testing is limited due to fixture development requirements.
Limited Repair
The Glunz & Jensen A/S part number is only available as a limited repair at our facility. Repairs to this item may be limited due to several reasons:
- Availability of parts
- Less than 100% test ability due to required support equipment
To have us attempt a repair on your Glunz & Jensen A/S part follow these steps:
Step 1 -
Click the Repair Now button above to add the part and complete the RMA form.
Step 2 -
Print the RMA form that is sent to your email, and put it in the box with the parts for repair.
Step 3 -
Mail the box to the address on the RMA.
After we receive your item, we will perform an inspection and an authorization to repair will be sent for your approval. Work will begin after your authorization is received.
