Repair Price: $ 484.00
Purchase
CSL Part Number: 30925
Product Overview: The Hitron HSU60-12 is a single-output industrial switching power supply that converts AC mains voltage to regulated 12VDC output. It delivers 60 watts of power, suitable for industrial control systems, automation equipment, and embedded computing applications. The unit features a compact enclosed design with screw terminals for connections and built-in protection circuits. It employs a UC3524 PWM controller IC for regulation and includes input filtering capacitors and output rectification stages typical of switch-mode topology.
Category: Power Supply
Manufacturer: Hitron Electronics
Manufacturer Part Number: HSU60-12
Power supplies are tested with a minimum 4-hour burn-in, under load.
Common Failures
One prevalent issue with this product is a "no power" condition, where the power indicator is on but the system does not run. This is often due to a failure in supplying the correct voltage outputs, expected to be 12VDC but measuring significantly lower.
Repair Approach
The initial diagnostic approach involved replacing defective output capacitors. Additionally, input capacitors were replaced after one was found open, which was suspected to contribute to the original problem. Testing methods included unsoldering daughter boards for easier access to test components such as ICs.
Testing & Quality
The unit underwent extensive diagnostic and functional testing. After replacing all low-voltage capacitors and ensuring correct connections, the issue persisted, resulting in no output voltage. The challenges in identifying and repairing the defective components led to the decision to return the unit unrepaired.
Service and repair your broken Hitron Electronics part
We can repair your Hitron Electronics model HSU60-12 in our facility. Let our skilled technicians get your Hitron Electronics back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
