KB Electronics KBWM-120 (9380C) Vari Drive FHP DC Motor

Repair

Repair Price: $ 328.00

Repair Now

Purchase

https://controlrepair.com/web/image/product.template/75180/image_1920?unique=3406b18
  • Condition

Purchase Price: $ 0.00 $ 0.00 328.0 USD

$ 0.00

This combination does not exist.

Add to Cart

CSL Part Number: 49740
Product Overview: A fractional-horsepower DC motor speed control that converts AC line input into adjustable DC output to drive permanent magnet and shunt-wound DC motors. Delivers up to 90V DC output with SCR-based regulation and a user-supplied horsepower resistor for current limiting. Used in conveyors, pumps, and small industrial machinery.
Category: DC Motor Controls
Manufacturer: KB Electronics
Manufacturer Synonyms: NIDEC
Manufacturer Part Number: KBWM-120 (9380C)
Also Known As(AKA): 9380 P/N

Common Failures

This product may experience issues including shorted components, missing fuses, failed integrated circuits, and damaged resistors. Please note that a horsepower resistor must be supplied by the user to ensure full operational capability.

Repair Approach

Our repair process may involve replacing shorted SCRs, installing appropriate fuses, and replacing faulty integrated circuits such as LM393, LM324, and LM358, along with damaged resistors. Capacitors may also be replaced to help ensure stability. Control adjustments are made as necessary to meet specified voltage outputs.

Testing & Quality

Following repair, the product undergoes testing, which may include a run-time test on a motor. Adjustments are performed to achieve the required output settings before cleaning and final inspection.

Service and repair your broken KB Electronics part


We can repair your KB Electronics model KBWM-120 (9380C) in our facility. Let our skilled technicians get your KB Electronics back in operation quickly.


Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.

Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.

Step 3 - Ship or mail the box to the address listed on the RMA.
