Lippert 2020003067 OneControl 4-PT Motorized Advantage Leveler
Repair
Repair Price: $ 320.00
Purchase
CSL Part Number: 122083
Product Overview: The Lippert 3-Point Leveling Control Plus Slide (part number 175227) is a microcontroller-based hydraulic leveling system control unit for recreational vehicles. It interfaces with a keypad to manage automatic and manual leveling operations using three hydraulic jacks. The controller monitors inputs including park brake status, ignition state, jack position sensors, and accelerometer data to maintain vehicle level. It provides switched 12VDC outputs to control hydraulic solenoid valves and includes safety interlocks to prevent operation while driving. Common applications include motorhomes and large travel trailers equipped with Lippert hydraulic leveling systems.
Category: Control Assembly
Manufacturer: Lippert
Manufacturer Part Number: 2020003067
Also Known As(AKA): 26095
Send keypad in with this unit.
Common Failures
The Lippert 3-point leveling control unit commonly experiences issues such as non-responsiveness to touchpad input, incorrect power distribution, and failure of leveling jacks in auto mode. Alarms may indicate jacks are up when they are not, or the parking brake indicator may remain on despite engagement. Additionally, improper programming of the leveling point can lead to functionality errors.
Repair Approach
Repairs may involve replacing defective components, such as resistor networks and capacitors, which can cause malfunctions. Diagnostics may reveal other issues like blown fuses or damaged traces, which are addressed through component replacement and circuit repairs. Solutions may also include reprogramming the Level point and upgrading fixtures to restore proper function.
Testing & Quality
Testing procedures involve confirming communication with keypads, ensuring proper voltage supply, and diagnosing any issues with outputs through a series of manual and automated checks. Units undergo multiple levels of testing to verify reliability after repair. Testing under simulated operational conditions helps verify that functions are restored.
Service and repair your broken Lippert part
We can repair your Lippert model 2020003067 in our facility. Let our skilled technicians get your Lippert back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
