CSL Part Number: 80816
Product Overview: The 16WC20C005 is a control board designed by Makino for use in their SP43 machine tools. This board manages machine control functions and contains programmable logic components including an Altera FPGA chip and driver ICs. It features an 18-pin driver IC configuration for controlling multiple channels. The board is used in CNC machining centers and other Makino industrial equipment for coordinating system operations.
Category: Control Board
Manufacturer: Makino
Manufacturer Part Number: 16WC20C005
Also Known As(AKA): C106B
Failures on this board can cause the wire-feed-spool back-tension to not operate properly. Send your board in to us for repair.
Common Failures
Observed failures in this product can include damaged integrated circuits and driver components. In some cases, programmable logic devices may also be affected, which can prevent normal operation.
Repair Approach
Repairs depend on the extent of damage identified during evaluation. Driver ICs are a common component requiring replacement. Some programmable devices may not be serviceable if pre-programmed replacement components are not available. We evaluate each unit to determine what repair options are feasible.
Testing & Quality
Diagnostic testing is performed where possible to assess component condition and function. The extent of testing depends on the nature and severity of the damage found during evaluation.
Service and repair your broken Makino part
We can repair your Makino model 16WC20C005 in our facility. Let our skilled technicians get your Makino back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
