Repair
Repair Price: $ 424.00
Purchase
CSL Part Number: 35022
Product Overview: The S-22A Wire Feeder Motor Control (Miller part 149454) is a motor speed control board used in Miller wire feed welding systems. It regulates DC motor speed for consistent wire feeding during welding operations. The board uses pulse-width modulation via an SG3524 IC to control motor drive transistors (TIP147 and IRF540 MOSFET), with a 24VDC relay for switching. It accepts variable speed input commands and supports both continuous operation and jog modes for precise wire feed control in MIG and flux-cored welding applications.
Category: Welders
Manufacturer: Miller Electric
Manufacturer Part Number: 149454
Service and repair your broken Miller Electric part
We can repair your Miller Electric model 149454 in our facility. Let our skilled technicians get your Miller Electric back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
