CSL Part Number: 75774
Product Overview: The Omega DPG601-1K is a battery-powered digital pressure gauge measuring 0 to 1000 PSIG. It uses two 9-volt alkaline batteries and provides electronic pressure measurement for industrial process monitoring and test applications. The gauge displays pressure readings digitally and is commonly used where portable or local pressure indication is required. NIST-traceable calibration with certification is available for quality assurance and compliance requirements.
Category: Meters / Gauges / Readouts
Manufacturer: Omega
Manufacturer Synonyms: Omega Engineering
Manufacturer Part Number: DPG601-1K
Also Known As(AKA): OMEGA TECHNOLOGIES
Calibration services available with Certificate of Calibration
Common Failures
Common issues encountered with this product include low battery voltage and the need for periodic calibration. When battery voltage falls significantly below specification, display errors may occur upon insertion of new batteries. Poor battery terminal connections can also contribute to operational issues.
Repair Approach
Typical repairs may involve battery replacement when charge levels are insufficient. When poor solder connections are identified at the battery terminals, resoldering to the circuit board may be performed to restore proper functionality.
Testing & Quality
Following repair work, the product undergoes diagnostic testing to verify proper operation. Calibration services with NIST certification are available and may be recommended to maintain accuracy and reliability of the gauge.
Service and repair your broken Omega part
We can repair your Omega model DPG601-1K in our facility. Let our skilled technicians get your Omega back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
