Repair
Repair Price: $ 1,768.00
Purchase
CSL Part Number: 88043
Product Overview: The T150 Series is a handheld wireless transmitter used for remote control of industrial equipment such as cranes, hoists, and material handling systems. It communicates via radio frequency with a matching receiver to actuate switches, triggers, and E-stop functions. The unit operates on AA batteries or can be powered through a tethered connection. Internal circuitry includes a microprocessor, RF module, and multiple switch inputs routed through connector headers. The control board is typically embedded in potting compound for environmental protection, making component-level repairs labor-intensive.
Category: Transmitter
Manufacturer: Omnex
Manufacturer Part Number: ASSY 2242-44
Series: T150 Handheld Remote Controller
Also Known As(AKA): FW-T150A-12-A-0029R02
Whether it's a broken switch, no communication, remote doesn't connect, broken case, or intermittent operation, or if it's been run over by a truck, send us your remote and we'll have you communicating. The repair price listed on the website is the normal repair price. After we receive the unit, it will be evaluated and a repair price will be quoted based on the expected repairs required. The repair price can be significantly greater if the control board needs to be extracted from the potting compound.
Common Failures
The Omnex wireless transmitter may experience physical damage and corrosion affecting connectors and circuit board traces. Other observed issues include non-functional remotes due to missing battery covers, connectivity problems indicated by continuous flashing, and complete power failure due to broken or defective components.
Repair Approach
Repairs typically involve replacing corroded or defective components, such as pin headers, connectors, and batteries. When corrosion has damaged circuit traces, cleaning and repair of those traces are conducted. Potting material is removed and reapplied as needed. Wiring and connector orientation are verified and adjusted to match manufacturer specifications.
Testing & Quality
After repair, units undergo testing to verify functionality. This includes verifying pairing with receivers, assessing switch and connectivity functions, and conducting burn-in tests. Units that pass testing demonstrate communication with diagnostic tools and reliable operation across controls.
Service and repair your broken Omnex part
We can repair your Omnex model ASSY 2242-44 in our facility. Let our skilled technicians get your Omnex back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
