Omnex D180-000235 Rev C D180 Analog Expansion Module
Repair
Repair Price: $ 1,995.00
Purchase
CSL Part Number: 122495
Product Overview: The Omnex D180 is a proportional function expansion module used in wireless remote control systems to add additional proportional control channels. It works in conjunction with a paired receiver and transmitter to expand control capabilities in industrial equipment such as cranes, hoists, and mobile machinery. The module features RS-485 communication interface and operates on 5V and 6V power rails. It requires pairing with a matching receiver for proper operation and system testing.
Category: Receiver
Manufacturer: Omnex
Alternate Manufacturer Names: EATON
Manufacturer Part Number: D180-000235 Rev C
Series: D180
Brand: OMNEX Trusted Wireless
Also Known As(AKA): D180B-NR-NR-N-0013R08
Other Synonyms: EATON
If the PCB inside is burned up - no CSL repair
Common Failures
One of the common issues identified was a broken inductor, which led to power discrepancies. Specifically, the 5V and 6V lines demonstrated incorrect voltage levels due to the damaged component. Additionally, there were no activities observed on the RS-485 or CANBUS indicators.
Repair Approach
The primary repair involved replacing the broken inductor, which restored the correct voltage levels across the lines. Following the repair, the unit's LED indicators functioned correctly, providing a visible indication of the unit's operational state.
Testing & Quality
Units were subject to power-on testing, where functions such as voltage levels and LED operation were verified. Full system testing was limited by the absence of a matching transmitter, restricting the ability to confirm end-to-end functionality.
Service and repair your broken Omnex part
We can repair your Omnex model D180-000235 Rev C in our facility. Let our skilled technicians get your Omnex back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
