Repair
Repair Price: $ 720.00
Purchase
CSL Part Number: 84029
Product Overview: A 115VAC chart-drive motor for a circular chart recorder, providing the timed rotation that advances paper on a 7-day cycle. Used in industrial process monitoring and data logging applications to record variables such as temperature, pressure, or humidity over time.
Category: Chart Recorder / Data Logger
Manufacturer: Partlow
Manufacturer Synonyms: Despatch
Manufacturer Part Number: 411000000021-907
Series: ARC 4100 Circular Chart Recorder
Brand: Partlow
Common Failures
One reported issue was the rotation motor becoming warm but not turning. Evaluation revealed the motor's case cover was dented, preventing the motor from functioning properly.
Repair Approach
The repair process involved straightening the motor case cover and reinstalling it. This allowed the motor to operate correctly. The motor was tested by running it continuously to verify proper operation.
Testing & Quality
After repairs, the motor underwent testing, including running for an extended period to verify its functionality and stability. Further testing confirmed that the motor correctly advanced the chart paper without issues.
Service and repair your broken Partlow part
We can repair your Partlow model 411000000021-907 in our facility. Let our skilled technicians get your Partlow back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
