Raymond Corporation 840-001-095 Motor with Options

Repair

Repair Price: $ 1,772.00

Repair Now

Purchase

https://controlrepair.com/web/image/product.template/37198/image_1920?unique=0ee3c9e
  • Condition

Purchase Price: $ 0.00 $ 0.00 1772.0 USD

$ 0.00

This combination does not exist.

Add to Cart

CSL Part Number: 17902
Category: Motor Controls
Manufacturer: Raymond Corporation
Manufacturer Part Number: 840-001-095

Common Failures

Two primary issues have been identified in the repair history of this product: an open fuse affecting the +15V supply and a faulty SCR module which led to output problems when motors were connected in parallel.

Repair Approach

For the open fuse issue, components were replaced, including a fuse, capacitors, resistors, triacs, and adjustments were made to wire connectors and the reverse contactor. For the faulty SCR module, the module was replaced along with the neon light, resolving the output irregularity when motors were connected.

Testing & Quality

Repairs were verified through comprehensive testing. The motor's ability to rotate in both directions at 180V was confirmed post-repair. Additionally, a 2-hour test period was conducted to ensure the output issue was resolved, and it was verified that the motor's previous hunting and skipping behavior was eliminated.

Service and repair your broken Raymond Corporation part


We can repair your Raymond Corporation model 840-001-095 in our facility. Let our skilled technicians get your Raymond Corporation back in operation quickly.


Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.

Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.

Step 3 - Ship or mail the box to the address listed on the RMA.
