Repair
Repair Price: $ 1,268.00
Purchase
CSL Part Number: 84823
Product Overview: The MicroLim Line Isolation Monitor is a safety device that continuously measures line-to-ground impedance in ungrounded electrical systems to detect hazardous leakage currents. It operates from 85 to 265 VAC with selectable alarm thresholds of 2 mA or 5 mA, providing visual and audible alarms plus relay outputs when isolation degrades. Commonly used in medical facilities, operating rooms, and critical care environments where patient safety requires monitoring of isolated power systems. Features include front-panel LED displays, test functions, and configurable voltage settings for 120V or 240V applications.
Category: Line Isolation Monitor
Manufacturer: Square D
Alternate Manufacturer Names: IGD, Iso-Gard Series D, FEDERAL PIONEER
Manufacturer Part Number: 43134-007-50
Series: Iso-Gard Monitors
Other Synonyms: IGD, Iso-Gard Series D, FEDERAL PIONEER
Common Failures
Several units exhibited symptoms such as error displays, failure to start up, and intermittent alarms. Faulty capacitors, defective voltage selector switches, and defective solder joints were among the issues identified during evaluation.
Repair Approach
Repairs involved replacing faulty capacitors, addressing defective or corroded voltage selector switches, and repairing solder joints. Thorough cleaning and calibration were performed as needed.
Testing & Quality
Post-repair testing involved burn-in tests using in-house test jigs to verify performance under load. Tests confirmed that functions, including fault detection and relay operations, worked correctly.
Service and repair your broken Square D part
We can repair your Square D model 43134-007-50 in our facility. Let our skilled technicians get your Square D back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
