Repair Price: $ 1,556.00
Purchase
CSL Part Number: 84842
Product Overview: The Star Seiki PI470 is a multi-output DC power supply designed for robotic automation and injection molding systems. It provides regulated +5V, +12V, +24V, and +3.3V outputs for control logic, relay switching, and I/O modules. The unit incorporates multiple electromechanical relays (Omron G6B series and G2R types) for interlock control, mold positioning signals, and peripheral equipment coordination such as conveyors. It features optical communication ports, status LEDs for diagnostics, and modular input cards (THC-IN08). Commonly used in Star Seiki robotic systems interfacing with molding machines.
Category: Power Supply
Manufacturer: Star Seiki
Manufacturer Synonyms: Star Automation
Manufacturer Part Number: PI470
Common Failures
Common issues observed with this product include defective components such as relays and capacitors, corrosion, defective solder joints, and missing hardware. Some units have experienced intermittent issues such as overheating or alarms. Wrong voltage inputs have also contributed to damage in some cases.
Repair Approach
Repairs typically involve diagnostic testing using devices such as Digital Multimeters (DMM) and Huntron testers. Common repairs include replacing defective relays and capacitors, addressing corrosion, and re-soldering defective solder joints. Cleaning procedures are applied as needed. In some cases, missing parts are replaced.
Testing & Quality
Units are subjected to comprehensive testing procedures. This includes verifying core voltage levels (+12V, +5V, +3.3V), testing relays, and performing burn-in tests without load to check stability. While some components cannot be fully tested due to board design, units that pass testing demonstrate operational capability. "No Fault Detected" or "Burn-In Test" results indicate successful completion of our testing process.
Service and repair your broken Star Seiki part
We can repair your Star Seiki model PI470 in our facility. Let our skilled technicians get your Star Seiki back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
