Repair
Repair Price: $ 944.00
Purchase
CSL Part Number: 74529
Product Overview: The MCH22AL3016 is a multi-axis joystick control handle manufactured by Sundstrand Mobile Controls (also known as Sauer-Danfoss) within the MCH Series. It converts operator hand movements into proportional electrical signals for controlling mobile equipment such as construction machinery, material handlers, and forestry vehicles. The unit features multiple potentiometers or Hall-effect sensors for precise directional input and typically includes centering mechanisms with locking capability. Output signals correspond to joystick position and are used by electronic controllers to regulate hydraulic valves or electric drive systems in applications requiring intuitive, ergonomic operator control of multiple machine functions simultaneously.
Category: Joystick / Controller
Manufacturer: Sundstrand Mobile Controls
Alternate Manufacturer Names: SAUER-DANFOSS
Manufacturer Part Number: MCH22AL3016
Series: MCH Series Joystick - Control Handle
Other Synonyms: SAUER-DANFOSS
Some repair parts take 2 weeks plus delivery to receive.
Common Failures
Units commonly experience issues with components such as the control handle working intermittently, defective diodes, worn-out spur gears, and deteriorated rubber boots and seals. Corrosion has also been identified as a contributing factor to these failures.
Repair Approach
Repairs typically involve replacing defective components such as diodes, spur gears, and seals. The control handle and damaged rubber boots are also replaced as part of the repair process. After replacement, the functionality of the unit is verified using a scope to ensure all outputs are correct.
Testing & Quality
Post-repair, units undergo a burn-in test with a resistive load to ensure reliability and performance. All repairs are verified through multiple quality checks, including testing protocols to confirm proper operation. Quality checks are overseen by trained personnel to maintain high standards.
Service and repair your broken Sundstrand Mobile Controls part
We can repair your Sundstrand Mobile Controls model MCH22AL3016 in our facility. Let our skilled technicians get your Sundstrand Mobile Controls back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
