Repair
Repair Price: $ 744.00
Purchase
CSL Part Number: 81159
Product Overview: The 4500 Labeler Machine Control Board is the main controller for Trine's 4500 roll-fed wraparound labeling system, used in various consumer product packaging applications. This board manages labeling operations including encoder input processing, relay switching, and voltage regulation at +/-12VDC. It interfaces with encoders, sensors, and actuators to precisely control label application timing and positioning during high-speed packaging operations.
Category: Control Board
Manufacturer: Trine Machine
Alternate Manufacturer Names: Accraply
Manufacturer Part Number: 6200
Brand: Trine
Other Synonyms: Accraply
The 4500 roll fed wraparound system provides labeling solutions for multiple consumer industries. Our technicians can repair your controller to get your machine up and running.
Common Failures
One of the common issues with this product involves capacitors with elevated equivalent series resistance (ESR). While current performance may not be severely affected, this condition can lead to future issues. Additionally, some buttons may appear unresponsive depending on the unit's configuration and intended application.
Repair Approach
The standard repair process includes replacing affected capacitors to address ESR-related concerns. Technicians also inspect the equipment for physical damage, such as bent component leads, which could cause operational issues.
Testing & Quality
After repairs, the product undergoes diagnostic and functional testing. Output and voltage levels are verified to ensure they align with expected values. Post-repair tests confirm that various functions operate correctly using CSL test equipment and procedures.
Service and repair your broken Trine Machine part
We can repair your Trine Machine model 6200 in our facility. Let our skilled technicians get your Trine Machine back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
