Repair
Repair Price: $ 428.00
Purchase
CSL Part Number: 17898
Product Overview: The Hytronic HCM Control Board is an industrial control module used primarily in Hytronic cutting machines, also known as clicker presses. The HCM-860A96-1 manages machine operation and safety functions including trip control. It features multiple electrolytic capacitors rated from 1uF to 250uF at various voltages (50V to 250V) that are critical to proper circuit operation. This board is commonly found in paper processing and material cutting applications where precision hydraulic press control is required.
Category: Control Board
Manufacturer: USM
Manufacturer Synonyms: United Shoe Machine, SAMCO
Manufacturer Part Number: HCM-860A96-1
Brand: Hytronic
Also Known As(AKA): HCM-861A96
Common Failures
Some of the frequently reported issues include the unit not tripping and not functioning at all. These issues may be traced back to defective capacitors or other component failures.
Repair Approach
Repairs may involve replacing faulty capacitors or other defective components identified during evaluation. After replacing components, connections are resoldered as required to ensure proper electrical contact.
Testing & Quality
Post-repair, the unit undergoes testing including burn-in with load to verify functionality per standard procedure. Each replaced component is tested using appropriate equipment to verify performance before concluding the repair process.
Service and repair your broken USM part
We can repair your USM model HCM-860A96-1 in our facility. Let our skilled technicians get your USM back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
