Vectrax AT-300-020 Project Spindle Controller
Repair
Call for price
Purchase
CSL Part Number: 109075
Product Overview: The Vectrax AT-300-020 is an operator interface panel designed for MSC Vectrax GS16 milling machines. It provides spindle control functions including forward/reverse direction selection, spindle speed adjustment via dial, and emergency stop capabilities. The unit integrates multiple DPDT relays to manage spindle motor commands and tool change sequences. This interface serves as the primary operator control point for spindle operations on GS16 mills.
Category: Operator Interface
Manufacturer: Vectrax
Manufacturer Part Number: AT-300-020
Please include wiring diagrams and problem symptoms
Common Failures
This milling machine board may exhibit issues related to vibration sensitivity, particularly during tool changes. Reported symptoms have included fault registration that requires a complete power cycle to clear, incorrect indicator readings, and unexpected spindle behavior during tool changes.
Repair Approach
Our evaluation process includes diagnostic testing to identify any components affected by vibration or other operational stress. Once the unit is received and reviewed, we can provide a quotation before any repair work begins. Repairs may include replacing components found to be defective or near failure. Time and Materials work is billed for labor and material spent attempting repair and is not warrantied.
Testing & Quality
Repaired boards undergo component-level testing and burn-in procedures to verify functionality. Full system-level testing is not performed. We test at the module level to confirm that the board operates as expected after repair.
Limited Repair
The Vectrax part number is only available as a limited repair at our facility. Repairs to this item may be limited due to several reasons:
- Availability of parts
- Less than 100% test ability due to required support equipment
To have us attempt a repair on your Vectrax part follow these steps:
Step 1 -
Click the Repair Now button above to add the part and complete the RMA form.
Step 2 -
Print the RMA form that is sent to your email, and put it in the box with the parts for repair.
Step 3 -
Mail the box to the address on the RMA.
After we receive your item, we will perform an inspection and an authorization to repair will be sent for your approval. Work will begin after your authorization is received.
