Repair Price: $ 940.00
Purchase
CSL Part Number: 81784
Product Overview: The Atwood Auto Controller Ford Levelegs 66275 REV 5 is a microprocessor-based control module that manages automatic leveling systems for Ford-chassis recreational vehicles. It controls four motorized leveling jacks (front driver, front passenger, rear driver, rear passenger), monitoring current draw through each channel to detect ground contact and obstruction. The controller interfaces with a dash-mounted keypad and supports both automatic and manual leveling modes. It features dual H-bridge relays per channel, current-sense circuitry with ZXCT1010 ICs and 0.001-ohm shunt resistors, and integrated safety inputs for park brake and park/neutral detection. Common failure modes include relay burnout from overcurrent, current-sense component degradation (often caused by hot-glue adhesive lifting surface-mount parts), and corrosion damage to connectors and traces in harsh environments. The unit
Category: Control Assembly
Manufacturer: Atwood
Manufacturer Part Number: 66275
Also Known As(AKA): 66275 REV 5
Send your keypad AND controller (see diagram) and we will test them to isolate the problem to the keypad, controller, or wiring/jacks (minimum $75 checkout fee may apply). Excessive burn damage or corrosion will result in additional costs.
Common Failures
Common issues identified with this control unit include current sense component failures, relay malfunctions, and physical damage from improper handling or environmental factors. Connector issues caused by wear or corrosion may also occur. Reported symptoms include non-operational leveling legs, error indications, and units that do not power on or communicate with associated devices.
Repair Approach
Repairs may involve replacing defective components such as relays and current sense components. Preventative maintenance may include replacing known failure-prone parts and restoring damaged circuit traces. Corrective action for corrosion and application of conformal coating to reinforce exposed areas may be performed as needed. Diagnostic testing is performed post-repair to verify functionality.
Testing & Quality
After repairs, units undergo testing, which may include communication checks with keypads and operational tests with leveling legs. Successful repairs are verified through load testing to confirm that functionalities have been restored. This testing phase helps verify that units meet operational standards before return.
Service and repair your broken Atwood part
We can repair your Atwood model 66275 in our facility. Let our skilled technicians get your Atwood back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
