BEI Electronics H25 SERIES H25 Incremental Optical Encoder
Repair
Repair Price: $ 476.00
Purchase
CSL Part Number: 688
Product Overview: An incremental optical rotary encoder that converts shaft rotation into quadrature ABZ pulse outputs for position, speed, and direction feedback. Available in various resolutions, such as 1000 counts, with complementary outputs and a regulated 5V supply. Commonly used on stepper and industrial drive motors for motion control.
Category: Encoders / Tachometers / Resolvers
Manufacturer: BEI Electronics
Manufacturer Part Number: H25 SERIES
Series: H25 Encoder
Also Known As(AKA): BEI
Common Failures
Based on repair history, frequent issues include internal structural damage, lack of pulse output, oil contamination, misalignment, and damaged traces. These problems typically result from environmental factors or operational stress.
Repair Approach
Repairs often involve cleaning the unit, resoldering connections, adjusting outputs for balanced performance, and in some cases, replacing faulty components such as lamps and damaged traces. Adjustments are made to achieve a consistent 50% duty cycle, and alignment corrections are performed so that signals are properly timed with A leading B by 90°. Units exposed to oil or other contaminants receive thorough cleaning.
Testing & Quality
After repairs, units undergo testing, including a standard burn-in test lasting one hour. Testing confirms that all functions, including pulse outputs, operate as designed.
Service and repair your broken BEI Electronics part
We can repair your BEI Electronics model H25 SERIES in our facility. Let our skilled technicians get your BEI Electronics back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
