Repair
Repair Price: $ 1,200.00
Purchase
CSL Part Number: 83638
Product Overview: The Robicon (Halmar) 1PCI-24120-CL/OC-D-5 is a single-phase SCR power controller rated for 240V and 120 amps. It provides proportional control of AC power to resistive or inductive loads through phase-angle firing of silicon controlled rectifiers. Common applications include heat control in paper processing equipment, plastic extrusion systems, and industrial ovens. The controller accepts a 4-20mA input signal for setpoint control and features internal voltage regulation circuits and specialized multi-tap transformers for gate drive and control board power supplies.
Category: Power Controls
Manufacturer: Robicon
Alternate Manufacturer Names: Halmar Robicon
Manufacturer Part Number: 1PCI-24120-CL/OC-D-5
Series: 1PCI Single Phase Power Controller
Also Known As(AKA): Halmar
Other Synonyms: Halmar Robicon
Missing or bad fuses additional.
Common Failures
Units evaluated by CSL have shown issues such as low current output or no output. These problems have been linked to defective components including cracked resistors and faulty electrolytic capacitors. In some cases, a specialized transformer was found to be open-circuited and required rewinding or replacement.
Repair Approach
Repairs have included replacing defective or aging components such as electrolytic capacitors. When transformer issues were detected, components were rewound or replaced as needed. Repairs also included securing connections and cleaning to support unit operation.
Testing & Quality
Following repair, units are tested under load to verify performance. Function tests confirm that voltage levels are within expected ranges. Extended testing is performed to verify that repaired functions operate correctly.
Service and repair your broken Robicon part
We can repair your Robicon model 1PCI-24120-CL/OC-D-5 in our facility. Let our skilled technicians get your Robicon back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
