Repair
Repair Price: $ 924.00
Purchase
CSL Part Number: 101517
Product Overview: The Sauer-Danfoss 162F0585 is a CAN bus-enabled joystick controller from the 162F series, commonly used in Link Belt L125 and L130 front loaders. It integrates proportional control sensors with wiper assemblies for loader functions such as bucket curl and boom positioning, along with directional control switches for forward/reverse operation. The unit features membrane-style pushbuttons, internal potentiometers for analog motion sensing, and communicates via CAN bus protocol with the machine's transmission control unit. It utilizes a 12-pin MATE-N-LOK connector for power, discrete switch signals, and digital communication.
Category: Joystick / Controller
Manufacturer: Sauer-Danfoss
Manufacturer Part Number: 162F0585
Series: 162F Series Joystick
CAN-bus problems may impact price quoted.
Common Failures
Frequent issues with the Danfoss Joystick model 162F0585 include failure in the bucket curl function, unresponsive forward/reverse operations, and problematic up-down slider switches. Defective components such as slide switches, cables, and connectors are common root causes. Additional issues have been observed with components like the internal pot wiper and control circuit board.
Repair Approach
Our typical repair process involves diagnosing communication through the CAN bus, checking the wiring and switch functionalities, and replacing defective components such as connectors, switches, and wires. In several cases, new wire harnesses are created, or existing ones repaired. Boot and clamps are replaced as part of regular refurbishment to help restore the joystick's integrity.
Testing & Quality
Repaired joysticks undergo thorough testing, which may include verifying CAN bus communications, testing all switches, and a burn-in test without load. Testing procedures are reviewed by our technical team to support quality standards.
Limited Repair
The Sauer-Danfoss part number is only available as a limited repair at our facility. Repairs to this item may be limited due to several reasons:
- Availability of parts
- Less than 100% test ability due to required support equipment
To have us attempt a repair on your Sauer-Danfoss part follow these steps:
Step 1 -
Click the Repair Now button above to add the part and complete the RMA form.
Step 2 -
Print the RMA form that is sent to your email, and put it in the box with the parts for repair.
Step 3 -
Mail the box to the address on the RMA.
After we receive your item, we will perform an inspection and an authorization to repair will be sent for your approval. Work will begin after your authorization is received.
