CSL Part Number: 80410
Product Overview: The Watlow 981C is a 1/8 DIN ramping controller designed for precise temperature control in industrial processes. Part of the 981-984 series, it features a single thermocouple input and dual outputs with green dual displays. The unit supports programmable ramping setpoint operation, allowing gradual temperature increases or decreases. Available in horizontal (981) or vertical (982) mounting configurations, these controllers can be configured with up to 2 inputs and 4 outputs depending on the model, making them versatile for applications requiring multi-zone temperature management in paper processing, plastics, and manufacturing equipment.
Category: Temperature Control
Manufacturer: Watlow
Manufacturer Part Number: 981C-10CA-JAGG
Series: 982 Series Teamperature Control
Brand: Watlow
Common Failures
Key issues identified with the Watlow 981C-Jagg controller include cracked up/down arrows on the membrane keypad due to use. Electrolytic capacitors are also evaluated during inspection.
Repair Approach
The repair process involves a thorough diagnostic assessment, including calibration verification of the thermocouple temperature readings and evaluation of the backup battery status. Electrolytic capacitors are replaced when found faulty or as needed based on unit condition.
Testing & Quality
Post-repair, the unit undergoes testing. It is set up for type C thermocouples and subjected to a burn-in test at 300°C. The testing process verifies the unit's readings against standard equipment to confirm functionality.
Service and repair your broken Watlow part
We can repair your Watlow model 981C-10CA-JAGG in our facility. Let our skilled technicians get your Watlow back in operation quickly.
Step 1 - Click the green 'Repair Now' button above to add the part and then complete the RMA.
Step 2 - The RMA form will be sent to you via email. Print the RMA form and put it in a box with the item(s) for repair.
Step 3 - Ship or mail the box to the address listed on the RMA.
